Accurate measurements and reliable connectivity
SRM 2030 is a tamper-proof solution of speed limitation for road vehicles such as trucks, buses, and vans. Speed limiter and the governor have sampling rate up to every 0.2 seconds, providing real-time data that includes the date, time, speed, and GPS coordinates of each event and violation. All the data can be stored on board, transmitted to cloud or servers as well retrieved to USB memory stick or computer or printed directly from the device.
Scalability and adaptation to different user needs
Thanks to the use of the latest IT and cloud technologies, data from thousands of devices being in motion can simultaneously serve information’s for various end users - depending on the obtained permissions. Regardless of whether it is a police controller, vehicle owner, service workshop or driver. Data can also be transmitted to autonomous traffic control systems.
Functions and technical specifications
Control unit SRM 2030.
Tamper proof – if the sensor is cut, the vehicle speed is limited to 40 kph and the unit transmits an alert to system provider /government authority/
ndependent power supply in case of car battery disconnection
Automatic and programable triggers to the system provider (loss power, loss connection between limiter and storage or limiting system, car battery)
Warning indication signal is provided when vehicle reaches 95% of the designated speed, and a continuous warning is provided when the vehicle is in an overspeed state
Data stored onboard for the last 72 h
GSM/GPRS – Connectivity to system provider
GPS – positioning system transmitting vehicle coordinates to the system provider
Diagnostics RS 232 / USB interface for diagnostics, printing and configuration
General Inverse polarity and overload protection
Nominal voltage 12 V and 24 V
Operating voltage 8 V to 32 V
Operating temperature -40°C to +85°C (in acc. with IEC 68-2-38)
Protection class IP 44 (installed inside vehicle)
Vibration and temperature tests IEC 68-2-36, IEC 68-2-14
Standards Approved in accordance with EU Directives 95/54
(EMC) and 92/24 (speed limitation)
Meets Nigerian, Kenyan, Ethiopian, UAE Standards
